Dimensions

Height: 8.2"
Width: 12.6"
Depth/Single: 1.0"
Depth/Double: 2.1"

Series Features

• Requires No Electrical Supply

• Internally Illuminated Glass Tubes
  Coated with Zinc Phosphor and Tritium Gas
• Initial Brightness
  0.15 Foot Lamberts (10 Years)
  0.18 Foot Lamberts (15 Years)
  0.25 Foot Lamberts (20 Years)
• End-of-Life Brightness Exceeds Minimum Code
  Requirement of .06 Foot Lamberts

• Requires No Battery Supply

• 10-, 15- or 20-Year Illumination

• No Internal or External Wiring Required
• Completely Sealed
• Explosion Proof
• Water Proof
• Corrosion, Mold and Vapor Proof
• Operating Range: -60°~ +180°F
• High Impact, ABS Fire-Retardant Case
• LEXAN® Cover
• Ceiling, End or Back Mount
• Universal Arrow Configuration
• Mist White Finish
• Complies with NFPA Life Safety Code, NRC, OSHA
  and Council of American Building Officials
• UL Listed
